Nintendo Switch 2 console

Size:

Approx. 166mm x 272mm x 13.9mm (with Joy-Con 2 controllers attached)

 The maximum thickness from the tip of the Control Sticks to the protruding parts of the ZL / ZR Buttons is 30.7mm.

Weight:

Approx. 401g
(With Joy-Con 2 controllers attached: approx. 534g)

Screen:

Capacitive touch screen / 7.9 inch wide colour gamut LCD screen /
1920x1080 resolution
HDR10 support / VRR up to 120 Hz

CPU/GPU:

Custom processor made by NVIDIA

System memory:

256 GB (UFS)

 A portion of internal storage is reserved for use by the system.

Communication features:

Wireless LAN (Wi-Fi 6) / Bluetooth
In TV mode, it's also possible to use a wired LAN connection.

Video output:

Maximum resolution: 3840x2160, 60 fps
Supports 120 fps when 1920x1080/2560x1440 resolutions are selected
Supports HDR10

 Output via HDMI cable in TV mode. In tabletop mode and handheld mode, the maximum resolution is 1920x1080, which matches the screen resolution.

Audio output:

Supports linear PCM 5.1ch
Output via HDMI cable in TV mode.

 Surround sound effect can be applied when outputting to headphones or to the built-in speaker (surround sound effect when outputting to the built-in speaker requires a system update).

Speakers:

Stereo

 The independent enclosure structure provides natural, clear sound quality.

Microphone:

Built-in microphone (monaural)

 Noise cancellation, echo cancellation and auto gain control provide a more comfortable voice chat experience.

Buttons:

POWER Button / Volume buttons

USB ports:

2 USB Type-C portsThe port on the bottom is used for charging or for connecting to the Nintendo Switch 2 dock. The port on the top is used to connect accessories or for charging.

Audio jack:

4 pole stereo 3.5mm mini plug (CTIA standard)

 Nintendo cannot guarantee functionality with all products.

Game card slot:

Both Nintendo Switch 2 and Nintendo Switch game cards can be inserted.

microSD Express card slot:

Compatible with microSD Express cards only (up to 2 TB)

 A system update via an internet connection is required to use microSD Express cards.
microSD cards that are not of microSD Express standard can only be used to copy screenshots and videos from Nintendo Switch.

Sensors:

Accelerometer, gyroscope, brightness sensor

Operating environment:

Temperature: 5 - 35°C / Humidity: 20 - 80%

Internal battery:

Lithium ion battery / battery capacity 5220 mAh

 The internal battery cannot be removed. If replacement is necessary, please contact your local Authorized Nintendo Service Center.

Battery life:

Approx. 2 - 6.5 hours

 This time is an estimate. The battery life will depend on the games you play and usage conditions.

Charging time:

Approx. 3 hours

 This is the time taken to charge while the console is in sleep mode.
